Product Overview

100 Watt - LED HID Replacement; 4K; EX39; Type B Ballast Bypass; 120-277 Volt

Standard Information

Category:

Light Bulbs

Subcategory:

LED Bulbs

Finish:

White

Style:

Traditional

Lumens:

3300+

Kelvin:

3501-4000

Wattage:

100w

Refinement Options

Category:

LED

Sub-Category:

HID Replacements

Volts:

120V-277V

Bulb Hours:

50000

Bulb Kelvin:

4000K

Bulb Shape:

HB51

Diameter:

6.34

EA Length:

9.49

Harmonized Codes:

8539.52.0091

Length:

8.15

Lumens:

15500L

Shap Carton Width:

7.72

Ship Carton Height:

7.48

Ship Weight:

3.5

Warranty:

5 Year Limited - Hi-Pro

Weight:

2.16

BAA Compliant:

No

Ballast Bypass Direct:

Ballast Bypass

Ballasting Requirements:

Ballast Bypass

Beam Spread:

180

Bulb ANSI Base:

EX39

Bulb Base:

Mogul Extended

Bulb Finish:

White

Burning Position:

Base Up

Carton Cubic Feet:

0.3171

Cartons Per Unit:

1

CCT Selectable:

No

CEC:

Exempt - Base Not Regulated

CEC Terse:

Lawful for sale in California

CEC Web Text:

Lawful for sale

Color Temprature:

Cool White

Country Of Origin:

China

CRI:

80+

DLC Approved:

Yes

DLC Classification:

Standard

DLC ID:

PW4XW9GM

DLC Primary Use:

Replacement Lamps for High-Bay Luminaires (Type B)

Efficacy:

155.00 LPW

Enclosed Fixture Use:

Yes

Enclosure Rating:

Enclosed Rated Lamp

FCC Compliant:

Yes

Feature 1:

4000K Cool White Light

Feature 2:

Advanced Passive Heat Dissipation

Feature 3:

Wide, 180 degree Beam Angle

Feature 4:

Long neck design fits more fixtures

Feature 5:

6kV built-in surge protection

Feature 6:

Rated for Use in Enclosed Fixtures

Feature 7:

Lawful for sale in California

Flourescent Equivalent:

150W

HID Equivalent:

400W

Housing Color:

White

Incandescent Equivalent:

500W

Indoor Outdoor:

Indoor;Outdoor

Installation Notes:

Not for use in vapor tight fixtures. Vertical Only with base up

IOT Enabled:

No

IP Rating:

IP40

JA8 Compliant:

No

Lamp Ballast Type A/B/C:

Type B

Lamp Filament:

LED

Lens:

Yes

Lens Finish:

Clear

Lens Material:

Glass

Location Rating:

Damp

Long Description:

SATCO NUVO's S13152 100-watt high bay LED lamp is a versatile and efficient lighting solution for those difficult lighting situations. Illuminate warehouses, gymnasiums, health clubs, and factories with this high lumen, LED lamp. Reduce maintenance and

Material:

Plastic

Minimum Compartment Size:

Diameter: 11.81 in. Height: 13.78 in.

NSF Approved:

Yes

Operating Frequency:

50/60Hz

Operating Temp:

-40C (-40F) to +60C (+140F)

Order In Multiples Of:

1

Pack Type:

Box

Power Factor:

0.9

Quantity In Pack:

1

RoHS Compliant:

Yes

Romance Copy:

SATCO NUVO's 100-watt high bay LED lamp is a versatile and efficient lighting solution for those difficult lighting situations. Illuminate warehouses, gymnasiums, health clubs, and factories with this high lumen, LED lamp. Reduce maintenance and energy

SDS class:

LED_Lamp

Short Description:

100W/LED/HID-HB/840/120-277V

Style:

Contemporary

Surge Protection:

Built-in surge protection - 6KV

Technology:

LED

Title 20 Compliant:

Exempt

Title 24 Compliant:

No

Total Harmonic Distortion:

20%

Wattage Selectable:

No

Watts:

100W

Manufacturer Info

Manufactured By:

Satco Products Inc.
