Product Overview

100 Watt; LED HID Replacement; 5000K; Mogul extended base; 100-277 Volt

Standard Information

Category:

Light Bulbs

Subcategory:

LED Bulbs

Style:

Traditional

Lumens:

3300+

Kelvin:

4501-5000

Wattage:

100w

Refinement Options

Category:

LED

Sub-Category:

HID Replacements

Volts:

120V-277V

Bulb Dimmable:

Yes-Dimmable

Bulb Hours:

50000

Bulb Kelvin:

5000K

Bulb Shape:

Integrated LED

Diameter:

4.6

EA Length:

14.23

Harmonized Codes:

8539.52.0091

Length:

12.35

Lumens:

15000L

Shap Carton Width:

8.73

Ship Carton Height:

6.48

Ship Weight:

3.56

Warranty:

5-Years

Weight:

3.19

BAA Compliant:

No

Beam Spread:

360

Bulb ANSI Base:

EX39

Bulb Base:

Mogul Extended

Bulb Finish:

Clear

Burning Position:

Universal

Carton Cubic Feet:

0.4659

Cartons Per Unit:

1

CCT Selectable:

No

CEC:

Exempt - Base Not Regulated

CEC Terse:

Lawful for sale in California

CEC Web Text:

Lawful for sale

Color Temprature:

Natural Light

Country Of Origin:

China

CRI:

80+

Dimmable Down To:

100 to 20 percent

Dimmable Function:

Dimmable with optional modules

DLC Approved:

Yes

DLC Classification:

Standard; Standard; Standard

DLC ID:

PL66LMJ6RES1; PLDRT7BU9AXX; PLUM173LZEGB

DLC Primary Use:

Replacement Lamps for Outdoor Pole/Arm-Mounted Decorative Luminaires (Type B); Replacement Lamps for Outdoor Pole/Arm-Mounted Decorative Luminaires (Type B); Replacement Lamps for High-Bay Luminaires (Type B)

Efficacy:

150.00 LPW

Enclosed Fixture Use:

Yes

Enclosure Rating:

Enclosed Rated Lamp

FCC Compliant:

Yes

Feature 1:

MOL: 12.35 inches, MOD: 4.60 inches

Feature 2:

Clear Finish

Feature 3:

Damp rated for indoor and outdoor use

Feature 4:

Mogul Extended Base

Feature 5:

Material: Aluminum

Feature 6:

Lens Material: Polycarbonate

Feature 7:

Has sensor

Feature 8:

FCC and RoHS compliant

Feature 9:

5-year limited warranty

HID Equivalent:

350W

Housing Color:

White/Grey

Incandescent Equivalent:

400W

Indoor Outdoor:

Indoor;Outdoor

Installation Notes:

Not for use in vapor tight fixtures.

IP Rating:

IP64

JA8 Compliant:

No

Lamp Filament:

LED

Lens:

Yes

Lens Finish:

Clear

Lens Material:

Polycarbonate (PC)

Location Rating:

Damp

Long Description:

SATCO NUVO's S13127 100-watt multi-angle rotating base LED lamp with a folding panel design replaces HID, CFL and incandescent lighting indoors and outdoors. Applications consist of: high bays, low bays, garages, gymnasiums and other high ceiling appli

Material:

Aluminum / Polycarbonate (PC)

Minimum Compartment Size:

Length: 9.85 in. Width: 9.85 in. Depth: 11.93 in.

NSF Approved:

No

Operating Frequency:

50/60Hz

Operating Temp:

-29C (-20F) to +45C (+113F)

Order In Multiples Of:

1

Pack Type:

Box

Photocell:

Has Photocell

Power Factor:

0.9

Quantity In Pack:

1

R9 Value:

19

RoHS Compliant:

Yes

Romance Copy:

SATCO NUVO's multi-angle rotating base LED lamp with a folding panel design replaces HID, CFL and incandescent lighting indoors and outdoors. Applications consist of: high bays, low bays, garages, gymnasiums and other high ceiling applications. Optiona

SDS class:

LED_Lamp

Short Description:

100W/LED/HP360/850

Style:

Utility

Surge Protection:

Built-in surge protection - 4KV

Technology:

LED

Thermal Management:

When the lamp body temperature is > 203F, the output will reduce to 75 percent; When the driver temperature is >257F, the output will reduce to 55 percent.

Title 20 Compliant:

Exempt

Title 24 Compliant:

No

Total Harmonic Distortion:

14.20%

Wattage Selectable:

No

Watts:

100W

Manufacturer Info

Manufactured By:

Satco Products Inc.
